14Mpa Hydraulic Winch Motor Omp 100 Replace Danfoss Omp 1510312 Orbit Motor

    Buy cheap 14Mpa Hydraulic Winch Motor Omp 100 Replace Danfoss Omp 1510312 Orbit Motor from wholesalers

    Buy cheap 14Mpa Hydraulic Winch Motor Omp 100 Replace Danfoss Omp 1510312 Orbit Motor from wholesalers
    • Buy cheap 14Mpa Hydraulic Winch Motor Omp 100 Replace Danfoss Omp 1510312 Orbit Motor from wholesalers
    • Buy cheap 14Mpa Hydraulic Winch Motor Omp 100 Replace Danfoss Omp 1510312 Orbit Motor from wholesalers

    14Mpa Hydraulic Winch Motor Omp 100 Replace Danfoss Omp 1510312 Orbit Motor

    Ask Lasest Price
    Brand Name : BLINCE
    Model Number : OMP 100cc hydraulic motor
    Certification : ISO9001:2008
    Price : Negotiation
    Payment Terms : T/T, Western Union, L/C, Paypal
    Supply Ability : 3000pc/month
    Delivery Time : 15-20days
    • Product Details
    • Company Profile

    14Mpa Hydraulic Winch Motor Omp 100 Replace Danfoss Omp 1510312 Orbit Motor

    Hydraulic Winch Motor omp 100 Replace danfoss omp 1510312 Orbit Motor


    Hydraulic winch motor omp 100 replace danfoss omp 1510312 orbit motor, OMP series motor are small volume, economical kind, which is designed with shaft distribution flow, which adapt the gear set design and provide compact volume, high power, low noise, high efficiency and low weight.


    Special features:

    1. Advanced manufacturing devices for the Gerotor gear set, which use low pressure of start-up, provide smooth, reliable operation and high efficiency.

    2. Oil Seal can bear high pressure of back and the motor can be used in parallel or in series.

    3. Design in the driver-linker and prolong operating life


    type

    OMP

    OMPH

    36

    OMP

    OMPH

    50

    OMP

    OMPH

    80

    OMP

    OMPH

    100

    OMP

    OMPH

    125

    OMP

    OMPH

    160

    OMP

    OMPH

    200

    OMP

    OMPH

    250

    OMP

    OMPH

    315

    OMP

    OMPH

    400

    OMP

    OMPH

    500

    Geometric displacement3651.777.796.2120.2157.2194.5240.3314.5389.5486.5
    Max.speed.(rpm)con.15001150770615490383310250192155120
    int.16501450960770615475385310240190150
    Max.torque(N.mcont.55100146182236302360383375360385
    int.76128186227290370440460555525560
    Max.output(KW)cont.8.010.010.011.010.010.010.08.57.06.05.0
    int11.512.012.013.012.012.012.010.58.57.06.0

    Max.pressure

    Drop(Mpa)

    cont.12.514141414141411976
    int16.517.517.517.517.517.517.5141410.59
    Max.flow(L/min)cont.5560606060606060606060
    int.6075757575757575757575


    Our motors adapt high quality cast iron, high technology machinery and testing machine to produce.

    Every motor must be tested before dispatched to our customers. Most our customers are satisfied

    with motor, because they are high efficiency, long life and low noise.




    Product Tags:

    omp motor



    danfoss omp


    Quality 14Mpa Hydraulic Winch Motor Omp 100 Replace Danfoss Omp 1510312 Orbit Motor for sale
